High Resolution, Aluminum, Low-Temp HMI with 7″ Wide Viewing Angle LCD Display, Advanced HMI
CPU – RAM/Flash 1.5GHz Quad-Core, 1GB/4GB
NEMA 4, IP66
Operating Temperature -20 – 55 C, -4 – 131 F
Ethernet Port- 2
Easy Access 2.0- Optional

Product Features:

• Display – 7″ TFT, Resolution -1024 x 600WVA LCD, LED Backlight
• Quad-core CPU with High Performance Dedicated 3D Processor
• Fan-less Cooling System
• Built-in 4GB Flash Memory and RTC
• COM2 and COM3 RS-485 2W supports MPI 187.5K, please use one at a time
• CAN Bus Supports CAN open, CAN Bus 2.0A/2.0B and SAE J1939
• Built-in Power Isolator
• NEMA4/ IP66 Compliant Front Panel
• The aluminum enclosure performs stably in harsh environment
• The operating temperature can be as low as -20 degrees C
