• Compatible with both ProLine and SmartLine controllers
• Rain shut-off settable from 18 1 (3 25 mm)
• Extended rain delay adds time to rain events before deficits begin to accumulate
• The unit can be mounted in sunlight or shade and in close proximity to the roof-line
• On-board diagnostics indicate battery and communication status
• Remote battery strength measurement from the SmartLine or ProLine controller
• 10-Year battery life (AAA lithium)
• Adjustable arm metal bracket for gutter thumb-screw or wall mount
• Operates on 900MHz frequency for superior range and reliability
• The maximum wireless distance from the controller to the sensor is a 1500 (457 m) line of sight.
• SLHUB-RF-5 wireless hub included with RFS5
• Freeze shut-off activated at 37F (3.0C)

The RFS5 is a wireless rain/freeze sensor operating on a 900 MHz bi-directional frequency. The maximum range is 1500 feet (457m) Line of Sight (LOS). The RFS5 is operable with all ProLine and SmartLine models and firmware versions. The RFS and RFSHUB-5 are pre-paired or synced at the factory for your convenience.

Documents:

• Weathermatic – RFS5 – Rain/Freeze Sensor Install Guide
