Ultrasonic forked sensor, switching signal on label and in label gap, m12 connector, 10 mm label width, 2 mm label gap, features teach input, horizontal plug outlet, short carriage, IP 65 protection

Series: 14
Principle of physics: optical and Ultrasonics
Application: Detection of transparent labels, Detection of non-transparent labels
Label width, min: 4 mm ultrasonic/2mm optical
Label gap, min: 2 mm
Medium: Transparent and not transparent
Response time: 0.2 ms
Supply voltage: 18 – 30 V, DC
Number of teach inputs: 1
Number of digital switching outputs: 2
Output 1 switching element: Transistor, Push-pull
Output 1 switching principle: IO-Link / NPN light switching (switching in the gap), PNP dark switching (switching on the label)
Output 2 switching element: Transistor, Push-pull
Output 2 switching principle: active low (normal operation high, event case low)
Type of connection: Connector
Thread size: M12
Plug outlet: Vertical (perpendicular to belt movement)
Mouth width: 4 mm
Mouth depth: 80 mm
Dimension: 22 mmx46.9 mmx96 mm
Housing material: Metal, Diecast zinc, galvanic nickel coating
Operational controls:Control Buttons
Degree of protection: IP 65
Certifications: c UL US

Ultrasonic forked sensor for reliable detection and universal application. With its large mouth width, this ultrasonic forked sensor is also suitable for leaflet labels and booklet labels.

Reliable detection of foil labels on foil carriers, foil labels on paper carriers, paper labels on paper carriers, metallic foil labels and thin metal foils
