Ultrasonic forked sensor, switching signal on label and in label gap, m12 connector, 10 mm label width, 2 mm label gap, features teach button and teach input, horizontal plug outlet, short carriage, IP 65 protection

Series: 14
Principle of physics: Ultrasonics
Application: Detection of non-transparent labels, Detection of transparent labels
Label width: 4 mm
Label gap: 2 mm
Medium: Transparent and not transparent
Response time: 0.2 ms
Supply voltage: 12 – 30 V, DC
Number of teach inputs: 1
Number of digital switching outputs: 2
Output 1 switching element: Transistor, Push-pull
Output 1 switching principle: Switching signal on label
Output 2 switching element: Transistor, Push-pull
Output 2 switching principle: Switching signal in label gap
Type of connection: Connector
Thread size: M12
Plug outlet: Horizontal (parallel to belt movement)
Mouth width: 4 mm
Mouth depth: 68.5 mm
Dimension: 20.7 mm x 48.2 mm x 101 mm
Housing material: Metal, Diecast zinc
Operational controls: Teach button
Degree of protection: IP 65
Certifications: c UL US

Ultrasonic forked sensor for reliable detection and universal application. With its large mouth width, this ultrasonic forked sensor is also suitable for leaflet labels and booklet labels.

Reliable detection of foil labels on foil carriers, foil labels on paper carriers, paper labels on paper carriers, metallic foil labels and thin metal foils
