Cable entry frame, Accepts3 QT insertsThe KEL-QUICK-E range is a compact single row system to route and seal pre-terminated cables as well as conduits or pneumatic hoses utilizing split QT grommets. The KEL-QUICK-E version is particularly suited for fl at connectors. The small frame is ideal for applications with limited space.
After populating the entry frame with QT grommets and cables, the cover lid is snapped onto the frame without using tools. A flat rubber gasket is included in the shipment.
IP rating: IP54
Material: Polyamide
Color: black (RAL 9005)
Flame class: UL94-V0, self-extinguishing
Temperature (C): -40 – 140 C (static)
Temperature (F): -40 – 284 F
Properties: Halogen free, Silicone free
Mounting type: Screw type mounting, QUICK system (tool-free)
Mounting height: 17 mm
Mounting height (inch): 0.669 “

Grommets must be purchased separately
