Icotek BPK 10-RF A: Plastic Blank Plate, Pluggable – 42015.002
Plastic blank plate, for KEL 10 seriesMaterial: PolypropyleneMaterial circular sealing: ElastomerLength: 101 mmWidth: 53 mmHeight: 10.3 mmSuitable for cut-out: KEL 10, KEL-U 10Cut-out length: 65 mmCut-out width: 36 mmFor wall thickness: 1.5 3 mm BPK-RF plu
Plastic blank plate, for KEL 10 seriesMaterial: Polypropylene
Material circular sealing: Elastomer
Length: 101 mm
Width: 53 mm
Height: 10.3 mm
Suitable for cut-out: KEL 10, KEL-U 10
Cut-out length: 65 mm
Cut-out width: 36 mm
For wall thickness: 1.5 3 mm
BPK-RF pluggable blank plates seal cut-outs for standard 10-pole 16-pole 24-pole industrial connectors with protection class IP54. For snapping into metal sheet plates (thickness from 1.5 to mm)
Advantages:
Fast mounting of the blank plates BPK-RF range by snapping into the cut-out
Integrated circular sealing
IP rating: IP54
NEMA rating: NEMAType12
Color: black (RAL 9005)
Flame class: UL94-V0, self-extinguishing
Temperature: -30 110 degrees Celcius
Properties: Halogen free, Silicone free
Click to download the Icotek BPK catalog
Click to download the Icotek 42015.002 Data Sheet
