Cable grommet, Large Grey, Adapter insertFor wire type: Adapter insert
Length: 42 mm
Width: 41 mm
Height: 19 mm

Due to large variety of split KT grommets, cables, pipes and conduits with various diameters can be routed. When assembled correctly, the split inserts are held tightly within the frame. Correctly sizing the grommet to the cable diameter ensures high degree of protection (up to IP65) and provides strain relief.

Cable grommets KT large are used with the following cable entries:
KEL KEL-U KEL-ER KEL-FG KVT range KEL 183

The model range KT large is designed for cable diameters from 16 to 34 mm.

ATG adapter inserts provide the possibility to hold small KT grommet to reduce the clamping range down to mm.

Enable routing of pre-terminated cables through cable entry frames and split cable glands

Available for big range of cable diameters

Material: Elastomer
Color: gray (similar RAL 7035)
Flame class: UL94-V0, self-extinguishing
Temperature: -40 90 degrees Celcius
Properties: Halogen free, Silicone free
With strain relief
